Overview

SERIAL ................ 58-1005-08-0
MODEL ................. "D"
TABLE SIZE ............ 30" X 16"
TABLE TRAVEL .......... 18" LONGITUDINAL
TABLE TRAVEL .......... 12" TRANSVERSE
HEAD VERTICAL TRAVEL .. 18"
TABLE POWER FEED ...... (16) 1/2 TO 7-1/2 IPM
SPINDLE TAPER ......... #30
SPINDLE SPEED ......... 250 TO 4000 RPM
SPINDLE TRAVEL ........ 3"
SPINDLE POWER FEED .... (8) .0002" TO .008"
*** ROTARY HEAD *** ... YES, 360 DEGREES
