SERIAL ....................... 2640489
YEAR NEW ..................... 1974
MODEL ........................ 3A (M-3500) SQUARE HEAD
SWING OVER BED ............... 24-1/2"
SWING OVER CARRIAGE .......... 18"
SPINDLE NOSE TO TURRET ....... 58-3/4"
SPINDLE HOLE ................. 6-1/4"
SPINDLE SPEEDS ............... (32) 12 TO 851 RPM
CARRIAGE LONGITUDINAL FEEDS .. (16) .005 TO .167 IPR
CARRIAGE CROSS FEEDS ......... (16) .002 TO .082 IPR
TURRET LONGITUDINAL FEEDS .... (16) .005 TO .167 IPR
TURRET CROSS FEEDS ........... (16) .003 TO .096 IPR
MAXIMUM LENGTH TURNED ........ 44-1/4"
CHUCK ........................ 21" 3 JAW
CHUCK WRENCH ................. POWER
TAPER ATTACHMENT ............. YES
CROSS SLIDING TURRET ......... YES
TURRET ....................... 5 POSITION
COOLANT ...................... YES
MOTOR ........................ HP
DIMENSIONS: 14' X 6' X 6' HIGH
| Specifications | ||
|---|---|---|
| Swing | 24.5 inches | |
Brand
WARNER & SWASEY
Type
Lathes, Turret
Stock No.
10254
 |
419-269-2000 |
Stock #: 10254
SERIAL ....................... 2640489
YEAR NEW ..................... 1974
MODEL ........................ 3A (M-3500) SQUARE HEAD
SWING OVER BED ............... 24-1/2"
SWING OVER CARRIAGE .......... 18"
SPINDLE NOSE TO TURRET ....... 58-3/4"
SPINDLE HOLE ................. 6-1/4"
SPINDLE SPEEDS ............... (32) 12 TO 851 RPM
CARRIAGE LONGITUDINAL FEEDS .. (16) .005 TO .167 IPR
CARRIAGE CROSS FEEDS ......... (16) .002 TO .082 IPR
TURRET LONGITUDINAL FEEDS .... (16) .005 TO .167 IPR
TURRET CROSS FEEDS ........... (16) .003 TO .096 IPR
MAXIMUM LENGTH TURNED ........ 44-1/4"
CHUCK ........................ 21" 3 JAW
CHUCK WRENCH ................. POWER
TAPER ATTACHMENT ............. YES
CROSS SLIDING TURRET ......... YES
TURRET ....................... 5 POSITION
COOLANT ...................... YES
MOTOR ........................ HP
DIMENSIONS: 14' X 6' X 6' HIGH
