| Specifications | ||
|---|---|---|
| Rect-Cap (H) | 25 inches | |
| Rect-Cap (W) | 40 inches | |
| Dimensions | 170” Length x 55″ Width x 100″ Height | |
| Weight | 7000 pounds | |
Brand
W.F. WELLS
Type
Saws, Band, Horizontal, Dual Column
Stock No.
12331
 |
419-269-2000 |
Stock #: 12331
Capacity, Rectangle ........... 25″ High x 40″ Wide
Capacity Round ................ 25.5″Weight Capacity ............... 15,000 lbsBlade Speed ................... 60 TO 500 SFPMBlade Size .................... 1½” X .050″ X 26′-6″Blade Tension ................. HydraulicBandwheel Size ................ 26″Vises ......................... HydraulicSawing Force .................. 0 TO 1,000 lbsCoolant Capacity .............. 15 GallonsHydraulic Capacity ............. 20 GallonsWork Height .................... 28″Outfeed Table .................. 24″ X 40″Vise Jaw Height ................ 17”Blade Break/Stall Switch ....... YesGuide Arm ...................... Hydraulic PositionedBlade Brush .................... Hydraulic PoweredBlade Tension Indicator ........ YesBlade Drive .................... 10 HP, AC Vector Drive
Hydraulic Drive ................ 5 HP Motor
