| Specifications | ||
|---|---|---|
| Rect-Cap (H) | 20.9 inches | |
| Rect-Cap (W) | 20.9 inches | |
| CNC Control | yes | |
| Type of CNC Control | AMADA | |
| Dimensions | 13′ L x 8′ W x 7′ H | |
| Weight | 15000 pounds | |
Brand
AMADA
Type
Saws, Band, Horizontal, Dual Column
Stock No.
18232
 |
419-269-2000 |
Stock #: 18232
SERIAL ............................ 50350002
MODEL ............................. HFA 530 CNC
YEAR .............................. 2006
ROUND CUTTING CAPACITY ............ 30-530MM
RECTANGLE CUTTING CAPACITY(WxH).... 1.18" TO 21"WORK LOAD CAPACITY ................ 8,811 LBS
SAW BLADE SIZE .................... 21'10" X 0.063" X 2-5/8"SAW BLADE SPEED ................... 50 TO 394 FPMTENSION CONTROL ................... HYDRAULIC
VISE OPERATION TYPE ............... SPLIT
VISE OPERATION CONTROL ............ HYDRAULIC FULL-STROKE CYLINDERSAW BLADE MOTOR ................... 7.5KW
MATERIAL INDEX MECHANISM .......... SHUTTLE TYPE
MATERIAL INDEX STROKE ............. 15.75"
MATERIAL FEED INDEX LENGTH ........ 0.39"-393.69"TABLE HEIGHT ABOVE FLOOR .......... 32.7"
SAW BLADE MOTOR ................... 7.5KW
MOTORS HYDRAULIC PUMP MOTOR ....... 5HP
CUTTING FLUID PUMP MOTOR .......... 0.25HP
AC INVERTER SPEED CHANGE .......... YES
WINDOW-BASED CNC CONTROLLER
AUTO TRIM CUT
AUTO INITIAL MATERIAL POSITION
BLADE DEVIATION MONITOR
CHIP CONVEYOR
30 BLOCK/10 STATION FOR DIFFERENT CUT LENGTH
