110 TON X 10' AMADA MODEL #HFE-1003S 6 AXIS HYDRAULIC PRESS BRAKE, NEW 2001: STOCK 16527

Stock #: 16527

Equipped With

SERIAL .................. V01268
MODEL ................... HFE-1003S
NEW ..................... 01-02-2001
CAPACITY ................ 110 TON
BED & RAM LENGTH ........ 122"
BETWEEN THE HOUSINGS .... 107"
THROAT .................. 16.5"
STROKE .................. 7.8"
SHUT HEIGHT ............. 18.5"
SPEED, APPROACH ......... 472 IPM
SPEED, BENDING .......... 47 IPM
SPEED, RETURN ........... 472 IPM
CONTROL ................. CNC 6 AXIS
BACK GAUGE .............. 4 AXIS CNC
CONTROLS ................ FOOT PEDALS
MOTOR ................... 25 HP

Buy Machines

110 TON X 10' AMADA MODEL #HFE-1003S 6 AXIS HYDRAULIC PRESS BRAKE, NEW 2001: STOCK 16527

Stock # 16527

Share Machine
Print Details

Machine Specifications

SERIAL .................. V01268
MODEL ................... HFE-1003S
NEW ..................... 01-02-2001
CAPACITY ................ 110 TON
BED & RAM LENGTH ........ 122"
BETWEEN THE HOUSINGS .... 107"
THROAT .................. 16.5"
STROKE .................. 7.8"
SHUT HEIGHT ............. 18.5"
SPEED, APPROACH ......... 472 IPM
SPEED, BENDING .......... 47 IPM
SPEED, RETURN ........... 472 IPM
CONTROL ................. CNC 6 AXIS
BACK GAUGE .............. 4 AXIS CNC
CONTROLS ................ FOOT PEDALS
MOTOR ................... 25 HP

Videos
Specifications
Dimensions 130 X 61 X 106" H
Weight 15500 pounds
