Machine Information

2500 LB TELEDYNE READCO MODEL #UPC-25 POWERED WELDING POSITIONER WITH POWERED ELEVATION : STOCK #14338

Stock #: 14338

Equipped With

SERIAL .......................... 103124
YEAR ............................ 1969
SIZE ............................ UPC-25
CAPACITY ........................ 2500 LBS
DIAMETER OF TABLE ............... 36"
VARIABLE SPEED ROTATION ......... YES
ELEVATION ....................... POWERED
TABLE TILTS ..................... 135 DEGREES
CENTERLINE OF TABLE TO FLOOR .... 36" MINIMUM TO 60" MAXIMUM
FORWARD & REVERSING ............. YES
PENDANT CONTROLS ................ YES
ROTATION MOTOR .................. 1/2 HORSEPOWER
TILT MOTOR ...................... 1/2 HORSEPOWER
FOOT PEDAL ...................... YES

Buy Machines

2500 LB TELEDYNE READCO MODEL #UPC-25 POWERED WELDING POSITIONER WITH POWERED ELEVATION : STOCK #14338

Stock # 14338

Share Machine
Print Details

Machine Specifications

SERIAL .......................... 103124
YEAR ............................ 1969
SIZE ............................ UPC-25
CAPACITY ........................ 2500 LBS
DIAMETER OF TABLE ............... 36"
VARIABLE SPEED ROTATION ......... YES
ELEVATION ....................... POWERED
TABLE TILTS ..................... 135 DEGREES
CENTERLINE OF TABLE TO FLOOR .... 36" MINIMUM TO 60" MAXIMUM
FORWARD & REVERSING ............. YES
PENDANT CONTROLS ................ YES
ROTATION MOTOR .................. 1/2 HORSEPOWER
TILT MOTOR ...................... 1/2 HORSEPOWER
FOOT PEDAL ...................... YES
