Stock #: 16264
SERIAL ................................ 4641MODEL ................................. 175 HI DUTYADJUSTABLE TABLE PRESSURE ............. UP TO 12,000 LBSDISTANCE BETWEEN UPRIGHTS ............. 10"TABLE SIZE ............................ 6" X 10"TABLE RISE HYDRAULICALLY .............. 1/2"TABLE RISE HAND ....................... 4"DIE SPACE FROM TABLE TO DIE SLIDE ..... 8"DIE SLIDE (ADJUSTABLE STROKE) ......... 3/8" TO 7"VARIABLE DIE SLIDE SPEED .............. 90-1" TO 15-6" STROKESDEPTH OF THROAT ....................... 3-1/2"TABLE HEIGHT .......................... 41-3/4"MARKING CAPACITY OF 1/4" CHARACTERS ... 3 LINESMARKING CAPACITY OF 3/16" CHARACTERS .. 4 LINESMARKING CAPACITY OF 1/8" CHARACTERS ... 5 LINESMARKING CAPACITY OF 1/16" CHARACTERS .. 8 LINES
Stock # 16264
SERIAL ................................ 4641
MODEL ................................. 175 HI DUTY
ADJUSTABLE TABLE PRESSURE ............. UP TO 12,000 LBS
DISTANCE BETWEEN UPRIGHTS ............. 10"
TABLE SIZE ............................ 6" X 10"
TABLE RISE HYDRAULICALLY .............. 1/2"
TABLE RISE HAND ....................... 4"
DIE SPACE FROM TABLE TO DIE SLIDE ..... 8"
DIE SLIDE (ADJUSTABLE STROKE) ......... 3/8" TO 7"
VARIABLE DIE SLIDE SPEED .............. 90-1" TO 15-6" STROKES
DEPTH OF THROAT ....................... 3-1/2"
TABLE HEIGHT .......................... 41-3/4"
MARKING CAPACITY OF 1/4" CHARACTERS ... 3 LINES
MARKING CAPACITY OF 3/16" CHARACTERS .. 4 LINES
MARKING CAPACITY OF 1/8" CHARACTERS ... 5 LINES
MARKING CAPACITY OF 1/16" CHARACTERS .. 8 LINES
| Specifications | ||
|---|---|---|
| Weight | 1550 pounds | |
