Brand
PTR
Type
Vertical Baler
Stock No.
18051
 |
419-269-2000 |
Stock #: 18051
SERIAL ......................... 06-5139MODEL .......................... 7230YEAR NEW ....................... 05/2006FINISHED BALE WIDTH ............ 72"FINISHED BALE DEPTH ............ 30"FINISHED BALE HEIGHT ........... 48"BALE WEIGHT .................... 1400 LBSBALE VOLUME .................... 60 CUBIC FTLOADING AREA ................... 72" WIDE X 25" HIGHSTROKE OF RAM .................. 48"DIAMETER OF RAM ................ 6"NUMBER OF TIE DOWN SLOTS ....... 5BALE EJECTOR ................... MANUALCYCLE TIME ..................... 56 SECONDSAUTO CYCLE ..................... YESEMERGENCY STOP ................. YESHYDRAULIC DRIVE MOTOR .......... 10 HORSEPOWER
DIMENSIONAL DATAOverall (Width x Depth x Height) 82 1/4" x 36" x 146 3/4" [209 x 91 x 386 cm]Feed Height 54 1/4" [138 cm]Baler Chamber (Depth x Height) 30" x 72" [76 x 183 cm]BALE SIZEBale Weight 1,100 - 1,400 Lbs [499 - 635 Kg]Bale Width 72" [152 cm]Bale Depth 30" [75 cm]Bale Height 48" [122 cm]PUMP, ELECTRIC SHIPPING WEIGHT DATAPump 10.5 GPM [39.75 L/m]Control Voltage 110 - 120 VacElectric 208 / 230 / 460 - 3 PhaseShip Weight 5,870 Lbs [2,585 Kg]SPECIFICATIONSCylinder Bore 6" [15.24 cm]Cylinder Rod 3 1/2" [8.9 cm]Rod Stroke 48" [122 cm]Motor 10 hp [7.45 Kw]Average Cycle Time 56 secSYSTEM PRESSUREWorking Pressure 2,000 psi [13,790 KPa]Relief Pressure 2,300 psi [1,5858 KPa]PLATEN FORCEWorking Force 56,549 lbs [251,543 N]Relief Force 65,031 lbs [289.272 N]RAM PRESSURENor Ram Pressure 26.5 psi [183 Kpa]Max Ram Pressure 30.5psi [210 Kpa]
