Stock #: 18390
SERIAL ................... 5625MODEL .................... VB5 24/20YEAR NEW ................. 2000HORIZONTAL CAPACITY ...... 20"VERTICAL CAPACITY ........ 24"VERTICAL CAPACITY ........ 15" @ 45 DEGVERTICAL CAPACITY ........ 9" @ 60 DEGBLADE SPEED .............. 40 TO 490 FPM
FEED FORCE ............... 0 TO 132 LBSBLADE DIMENSTIONS ........ 15'6-13/16" X 1-1/16" X .035"WHEEL DIAMETER ........... 20"TABLE HEIGHT ............. 38-3/16"WORKING SURFACE .......... 33-1/2" X 28"HYDRAULIC TANK CAPACITY .. 24.86 GALLONS
DRIVE MOTOR .............. 4 HP
Stock # 18390
SERIAL ................... 5625
MODEL .................... VB5 24/20
YEAR NEW ................. 2000
HORIZONTAL CAPACITY ...... 20"
VERTICAL CAPACITY ........ 24"
VERTICAL CAPACITY ........ 15" @ 45 DEG
VERTICAL CAPACITY ........ 9" @ 60 DEG
BLADE SPEED .............. 40 TO 490 FPM
FEED FORCE ............... 0 TO 132 LBSBLADE DIMENSTIONS ........ 15'6-13/16" X 1-1/16" X .035"
WHEEL DIAMETER ........... 20"
TABLE HEIGHT ............. 38-3/16"
WORKING SURFACE .......... 33-1/2" X 28"
HYDRAULIC TANK CAPACITY .. 24.86 GALLONS
DRIVE MOTOR .............. 4 HP
Videos | ||
---|---|---|
Specifications | ||
---|---|---|
Dimensions | 98" X 90" X 92" H | |
Weight | 2865 pounds |
