SERIAL ................... 14C-32
MODEL .................... 14C MAKINO REGAL SERVO SHIFT
SWING .................... 15"
SWING OVER CROSS ......... 10"
CENTERS .................. 30"
Brand
LEBLOND MAKINO
Type
Lathes, Engine
Stock No.
12912
 |
419-269-2000 |
Stock #: 12912
SERIAL ................... 14C-32
MODEL .................... 14C MAKINO REGAL SERVO SHIFT
SWING .................... 15"
SWING OVER CROSS ......... 10"
CENTERS .................. 30"
SPINDLE SPEEDS ........... (12) 45 TO 1,800 RPMSPINDLE NOSE ............. D1-6HOLE THROUGH SPINDLE ..... 2-1/4"THREADS INCH ............. (48) 2 TO 112 TPITHREADS METRIC ........... (40) 0.25 TO 14 MMFEEDS .................... (48) 0.0018" TO 0.104"
THREAD DIAL............... YESCROSS SLIDE TRAVEL ....... 8"TAIL STOCK QUILL TRAVEL .. 5"TAIL STOCK QUILL TAPER ... #4 MTCHUCK .................... 4 JAWCOOLANT .................. YESSPLASH GUARDS ............ YESMOTOR .................... 5 HP
