SERIAL ................................. 3-7117
Brand
KEARNEY & TRECKER
Type
Boring Mills, Horizontal, Table Type
Stock No.
21214
 |
419-269-2000 |
Stock #: 21214
SERIAL ................................. 3-7117MODEL .................................. 4CKWORKING SURFACE OF TABLE ............... 90" X 18"SPINDLE SPEEDS ......................... (24) 13 TO 1300 RPMCROSS AND LONGITUDINAL FEEDS ........... (32) 3/8 TO 90 IPMVERTICAL FEEDS ......................... (32) 3/16 TO 45 IPMLONGITUDINAL TRAVEL .................... 42"CROSS TRAVEL ........................... 14"VERTICAL TRAVEL ........................ 18"POWER RAPID TRAVERSE ................... 150 IPMSPINDLE TO TABLE ....................... 0" MINIMUM, 21" MAXIMUMTAPER IN SPINDLE ....................... #50 NSOVERARM SUPPORT ........................ YESCOOLANT ................................ YESRAPID MOTOR ............................ 5 HORSEPOWERMOTOR .................................. 25 HORSEPOWER
