#3 KEARNEY & TRECKER MODLE #320TF16 VERTICAL MILL: STOCK #13369

Stock #: 13369

Equipped With

SERIAL ............................ 2 / 9565
MODEL ............................. #320-TF16
AREA OF TABLE ..................... 72" X 15-1/2"
SPINDLE SPEEDS .................... (24) 15 TO 1500 RPM
LONGITUDINAL & CROSS FEEDS ........ (32) 3/8 TO 90 IPM
VERTICAL FEEDS .................... (32) 3/16 TO 45 IPM
LONGITUDINAL TRAVEL ............... 34"
CROSS TRAVEL ...................... 12"
VERTICAL KNEE TRAVEL .............. 18"
RAPID TRAVERSE .................... 150" IPM
TAPER IN SPINDLE .................. #50NS
COOLANT ........................... YES
RAPID TRAVERSE MOTOR .............. 3 HORSEPOER
MAIN MOTOR ........................ 20 HORSEPOWER

Buy Machines

#3 KEARNEY & TRECKER MODLE #320TF16 VERTICAL MILL: STOCK #13369

Stock # 13369

Share Machine
Print Details

Machine Specifications

SERIAL ............................ 2 / 9565
MODEL ............................. #320-TF16
AREA OF TABLE ..................... 72" X 15-1/2"
SPINDLE SPEEDS .................... (24) 15 TO 1500 RPM
LONGITUDINAL & CROSS FEEDS ........ (32) 3/8 TO 90 IPM
VERTICAL FEEDS .................... (32) 3/16 TO 45 IPM
LONGITUDINAL TRAVEL ............... 34"
CROSS TRAVEL ...................... 12"
VERTICAL KNEE TRAVEL .............. 18"
RAPID TRAVERSE .................... 150" IPM
TAPER IN SPINDLE .................. #50NS
COOLANT ........................... YES
RAPID TRAVERSE MOTOR .............. 3 HORSEPOER
MAIN MOTOR ........................ 20 HORSEPOWER

Specifications
Weight 10500 pounds
