Machine Information

6-AXIS FANUC ARC Mate 50iL ROBOT WELDING SYSTEM WITH LJ POSITIONER & LINCOLN WELDER: STOCK #16200

Stock #: 16200

Equipped With


SYSTEM CONSISTS OF:

FANUC ROBOT:
SERIAL .................. R00X13126
TYPE .................... A05B-1135-B007
YEAR NEW ................ 2000

MODEL ................... ARC Mate 50iL
NUMBER OF AXES .......... 6
PAYLOAD ................. 3 kg
REPEATABILITY ........... +/- 0.04 mm
STRUCTURE ............... ARTICULATED
MOTION SPEED & RANGE .... SEE SPECS IN PICTURE

FANUC CONTROLLER:
SERIAL .................. E00904149
TYPE .................... A05B-2419-B001
MODEL ................... SYSTEM R-J3
YEAR NEW ................ 2000
FANUC PENDANT CONTROL ... YES

TOUGH GUY REAMER & CLEARING STATION

LINCOLN WELDER:
SERIAL .................. U1010828707
MODEL ................... INVERTEC STT II

LINCOLN REMOTE CONTROLLER:
MODEL ................... STT-10

LINCOLN WIRE FEEDER:
SERIAL .................. 010101-3353
MODEL ................... SYNERGIC 7F

LJ WELDING POSITIONER:
SERIAL .................. 015
MODEL ................... 12P-700
WEIGHT CAPACITY ......... 1000 LBS
DIAMETER OF CHUCK ....... 12"
NUMBER OF CHUCK JAWS .... 3
ROTATION SPEED .......... 0 TO 100 RPM
VARAIABLE SPEED DRIVE ... YES, PENTA-DRIVE
HEAD TILT OPTION ........ YES
TILT DEGREE INDICATOR ... YES
FORWARD & REVERSE ....... YES
PENDANT CONTROLS ........ YES
FOOT PEDAL CONTROLS ..... YES
OUTBOARD SUPPORT ROLLER . YES, 1500 LBS CAPACITY




Fanuc ARC Mate 50iL Robot:

Suited for arc welding applications, this compact FANUC ARC Mate 50iL welding robot has six axes, serial link, and is electric servo driven. Designed for high-speed flexible and reliable performance, the ARC Mate 50iL is capable of arc welding, material handling, and process applications. The FANUC ARC Mate 50iL works with the FANUC RJ2 or the RJ3 controller.

Additional features include all motors and cables internally located to protect them from the harsh welding environment, compatible with all major brands of welding equipment, interfaces with most types of servo driven or indexing positioners. TI is evident that the design of this small robot arm is optimized for reliability. Cabling is routed through the center of the axis to reduce interference and protect the cables from the hazardous welding environment.
