Serial Number 109423
SPECIFICATIONS:
Blade Width: 5/16 – 3/4″
Blade Length: 188″
Blade Speed: 50 – 500 FPM
Welder Capacity: 5/16 – 3/4″
Worktable Travel Distance: 10″
Worktable T-Slots: 4
Band Wheels Number: 3
Band Wheels Size: 16-1/2″
Motor HP: 2.2
Throat Size (Band to Column): 41″
Maximum Work Height: 13″
Table Size: 26-1/4″ x 26-1/4″
Electrical: 220 / 440V (Wired 440) / 3PH
EQUIPPED WITH:
Hydraulic Power Feed Table, Blade Grinder & Welder, Chip Blower, Work Light
Brand
Not Specified
Type
Saws, Band, Vertical
Stock No.
18615
 |
419-269-2000 |
Stock #: 18615
Dake Johnson VH-40 Vertical Band Saw 41" x 13" #6710 #1Serial Number 109423
SPECIFICATIONS:
Blade Width: 5/16 – 3/4″
Blade Length: 188″
Blade Speed: 50 – 500 FPM
Welder Capacity: 5/16 – 3/4″
Worktable Travel Distance: 10″
Worktable T-Slots: 4
Band Wheels Number: 3
Band Wheels Size: 16-1/2″
Motor HP: 2.2
Throat Size (Band to Column): 41″
Maximum Work Height: 13″
Table Size: 26-1/4″ x 26-1/4″
Electrical: 220 / 440V (Wired 440) / 3PH
EQUIPPED WITH:
Hydraulic Power Feed Table, Blade Grinder & Welder, Chip Blower, Work Light
