Stock #: 18700
SERIAL ...................... 65U-4739
MODEL ....................... #1VBRCAPACITY ANGLE LEG OUT ...... 3" X 3" X 3/8"DIAMETER .................... 24"CAPACITY ANGLE LEG IN ....... 2-1/2" X 2-1/2" X 3/8"MINIMUM DIAMETER ............ 30"BEAMS ON FLANGE ............. 5' X 12-1/4 LBS TO 40" MINIMUMFLATS ON EDGE ............... 3" X 5/8" TO 36" MINIMUM DIAMETERFLATS ON FLAT ............... 6" X 1" TO 24" MINIMUM DIAMETERROUNDS ...................... 2" TO 24" MINIMUM DIAMETERSQUARES ..................... 1-3/4" TO 24" MINIMUM DIAMETERVARIABLE SPEEDS ............. 11.2 RPMLEG IN LEG OUT ATTACHMENT ... YESHYDRAULIC ADJUSTMENT ........ YESONE SHOT LUBE SYSTEM ........ YESMAIN MOTOR .................. 10 HORSEPOWER
Stock # 18700
SERIAL ...................... 65U-4739
MODEL ....................... #1VBRCAPACITY ANGLE LEG OUT ...... 3" X 3" X 3/8"
DIAMETER .................... 24"
CAPACITY ANGLE LEG IN ....... 2-1/2" X 2-1/2" X 3/8"
MINIMUM DIAMETER ............ 30"
BEAMS ON FLANGE ............. 5' X 12-1/4 LBS TO 40" MINIMUM
FLATS ON EDGE ............... 3" X 5/8" TO 36" MINIMUM DIAMETER
FLATS ON FLAT ............... 6" X 1" TO 24" MINIMUM DIAMETER
ROUNDS ...................... 2" TO 24" MINIMUM DIAMETER
SQUARES ..................... 1-3/4" TO 24" MINIMUM DIAMETER
VARIABLE SPEEDS ............. 11.2 RPM
LEG IN LEG OUT ATTACHMENT ... YES
HYDRAULIC ADJUSTMENT ........ YES
ONE SHOT LUBE SYSTEM ........ YES
MAIN MOTOR .................. 10 HORSEPOWER
