SERIAL .............................. 62290
MMODEL .............................. ACC-8-20DX
ELECTRO MAGNETIC CHUCK .............. 8" x 20"
LONGITUDAL TABLE TRAVEL ............. 25.59"
MAX TABLE LOAD ...................... 440 LBS
CROSS SADDLE TRAVEL ................. 9"
MAX DISTANCE UNDER WHEEL TO TABLE ... 15.6"
TABLE SPEED ......................... 1-83 FPM
CROSS SADDLE FEEDS .................. 0.02" - 0.40" (NTERMITTENT)
AUTOMATIC SPINDLE DOWNFEED RATE ..... 0.0002" - 0.0015" (INCREMENTAL)
RAPID VERTICAL SPINDLE RATE ......... 19 IPM
GRINDING WHEEL SIZE ................. 8" x 1" x 1 1/4"
VARIABLE CHUCK CONTROL .............. YES
AUTO LUBE SYSTEM .................... YES
SPLASH GUARD ........................ YES
MOTOR ............................... 2 HP
| Specifications | ||
|---|---|---|
| Dimensions | 95" x 63" x 70" | |
| Weight | 4000 pounds | |
Brand
OKAMOTO
Type
Grinders, Surface, Recip.
Stock No.
14526
 |
419-269-2000 |
Stock #: 14526
SERIAL .............................. 62290
MMODEL .............................. ACC-8-20DX
ELECTRO MAGNETIC CHUCK .............. 8" x 20"
LONGITUDAL TABLE TRAVEL ............. 25.59"
MAX TABLE LOAD ...................... 440 LBS
CROSS SADDLE TRAVEL ................. 9"
MAX DISTANCE UNDER WHEEL TO TABLE ... 15.6"
TABLE SPEED ......................... 1-83 FPM
CROSS SADDLE FEEDS .................. 0.02" - 0.40" (NTERMITTENT)
AUTOMATIC SPINDLE DOWNFEED RATE ..... 0.0002" - 0.0015" (INCREMENTAL)
RAPID VERTICAL SPINDLE RATE ......... 19 IPM
GRINDING WHEEL SIZE ................. 8" x 1" x 1 1/4"
VARIABLE CHUCK CONTROL .............. YES
AUTO LUBE SYSTEM .................... YES
SPLASH GUARD ........................ YES
MOTOR ............................... 2 HP
