| Specifications | ||
|---|---|---|
| Max Stock Width Capacity | 8 inches | |
| Dimensions | 3' X 3'6" X 4'8" | |
| Weight | 1200 pounds | |
Brand
LITTELL
Type
Coil Straighteners
Stock No.
17297
 |
419-269-2000 |
Stock #: 17297
SERIAL .......................... 59891-56MODEL ........................... 308-7PDLSTRAIGHTENER .................... 7 ROLL, 3 OVER 4CAPACITY, MILD STEEL ............ 8" X .041"
CAPACITY ........................ 3" X .050"DIAMETER OF ROLLS ............... 1-3/4"LENGTH OF ROLLS ................. 8-1/4"CENTER DISTANCE BETWEEN ROLLS ... 2-1/4"ENTRY PINCH ROLLS ............... YESDIAMETER OF PINCH ROLLS ......... 3-1/2"SPEED (VARIABLE) ................ 10 TO 60 FPMELECTRIC BRAKE .................. YESINDEPENDENT ROLL ADJUSTMENT ..... YESCONTROL ......................... DANCER ARMMOTOR, HORSEPOWER ............... 3/4
