SERIAL ................. 35122-40118
NUMBER OF STANDS ....... 5 ON 8 BASE
ARBOR DIAMETER ......... 2"
ROLL SPACE ............. 13"
HORIZONTAL CENTERS ..... 15"
VERTICAL ADJUSTMENT .... 4" TO 7"
LOWER SPINDLE TO BASE .. 7-1/4"
FLOOR TO TOP OF BASE ... 30"
ENTRY GUIDE ............ YES
SIDE PASS ROLLS ........ 3
TURKSHEAD .............. YES
MOTOR .................. 15 HP
| Specifications | ||
|---|---|---|
| Roll Diameter | 2 inches | |
| Number of Stands | 5 | |
| Diameter of Arbor | 2 inches | |
| Power | 15 horsepower | |
| Horiz Centers | 15 inches | |
| Vert Centers | 7 inches | |
| Dimensions | Height: 69" Length: 139.5" Width: 41.5" | |
Brand
YODER
Type
Roll Formers
Stock No.
10244
 |
419-269-2000 |
Stock #: 10244
SERIAL ................. 35122-40118
NUMBER OF STANDS ....... 5 ON 8 BASE
ARBOR DIAMETER ......... 2"
ROLL SPACE ............. 13"
HORIZONTAL CENTERS ..... 15"
VERTICAL ADJUSTMENT .... 4" TO 7"
LOWER SPINDLE TO BASE .. 7-1/4"
FLOOR TO TOP OF BASE ... 30"
ENTRY GUIDE ............ YES
SIDE PASS ROLLS ........ 3
TURKSHEAD .............. YES
MOTOR .................. 15 HP
