8 STAND X 2" X 13" YODER M2 ROLLFORMER: STOCK #10235

Stock #: 10235

Equipped With

MACHINE CURRENTLY TOOLED FOR 1-1/2" PREPAINTED, LOCK SEAM TUBING

SERIAL ................ Y8147 990
MODEL ................. M2
YEAR .................. 1990
NUMBER OF STANDS ...... 8
SPINDLE DIAMETER ...... 2"
ROLL SPACE ............ 13"
VERTICAL CENTER ....... 4" TO 8"
HORIZONTAL CENTER ..... 15"
BASE TO BOTTOM SHAFT .. 7.25" TO CENER
UNEQUAL GEARED ........ 1.33:1
VARIABLE SPEED ........ SOLID STATE AC MOTOR & CONTROLS
ENTRY EDGE GUIDE ...... YES
TUBE FORMER - 2 HORIZONTAL & 2 VERTICAL ROLLS
SIDE PASSES ........... 5
TURKSHEAD ............. YES
MOTOR ................. 15 HP

Buy Machines

8 STAND X 2" X 13" YODER M2 ROLLFORMER: STOCK #10235

Stock # 10235

Share Machine
Print Details

Machine Specifications

MACHINE CURRENTLY TOOLED FOR 1-1/2" PREPAINTED, LOCK SEAM TUBING

SERIAL ................ Y8147 990
MODEL ................. M2
YEAR .................. 1990
NUMBER OF STANDS ...... 8
SPINDLE DIAMETER ...... 2"
ROLL SPACE ............ 13"
VERTICAL CENTER ....... 4" TO 8"
HORIZONTAL CENTER ..... 15"
BASE TO BOTTOM SHAFT .. 7.25" TO CENER
UNEQUAL GEARED ........ 1.33:1
VARIABLE SPEED ........ SOLID STATE AC MOTOR & CONTROLS
ENTRY EDGE GUIDE ...... YES
TUBE FORMER - 2 HORIZONTAL & 2 VERTICAL ROLLS
SIDE PASSES ........... 5
TURKSHEAD ............. YES
MOTOR ................. 15 HP

Specifications
Roll Diameter 2 inches
Number of Stands 8
Diameter of Arbor 2 inches
Power 15 horsepower
Horiz Centers 15 inches
Vert Centers 8 inches
Dimensions 44.5W x 209.5L x 63"H
Weight 11300 pounds
