SERIAL .............................. 522055
MODEL ............................... #5
CONSTRUCTION ........................ HYDRAULIC
PUNCHING CAPACITY ................... 75 TON
PUNCHING DIAMETER THRU THICKNESS .... 1-1/4" THRU 3/4"
CAPACITY ANGLE @ 90 DEGREES ......... 5 " X 5" X 1/2"
CAPACITY ANGLE @ 45 DEGREES ......... 4" X 4" X 3/8"
CAPACITY ROUNDS ..................... 1-7/8"
CAPACITY SQUARES .................... 1-3/4"
CAPACITY FLATS ...................... 1" X 4" OR 1/4 "X 10"
CAPACITY TEES ....................... 4" X 4"X 3/8"
LENGTH OF BLADE ..................... 12"
DEPTH OF THROAT ..................... 20"
STROKE:.............................. 40"
NOTCHER ............................. YES
COPING .............................. YES
DUAL FOOT CONTROLS .................. YES
MAIN MOTOR .......................... 10 HORSEPOWER
| Specifications | ||
|---|---|---|
| Angle (L1) | 5 inches | |
| Angle (L2) | 5 inches | |
| Angle (T) | .5 inches | |
| Tonnage | 75 ounces | |
| Power | 10 horsepower | |
| Throat | 20 inches | |
| Dimensions | 76 X 60 X 84 H | |
| Weight | 8000 pounds | |
| Stroke | 40 inches | |
Brand
HILL-ACME
Type
Ironworkers
Stock No.
10158
 |
419-269-2000 |
Stock #: 10158
SERIAL .............................. 522055
MODEL ............................... #5
CONSTRUCTION ........................ HYDRAULIC
PUNCHING CAPACITY ................... 75 TON
PUNCHING DIAMETER THRU THICKNESS .... 1-1/4" THRU 3/4"
CAPACITY ANGLE @ 90 DEGREES ......... 5 " X 5" X 1/2"
CAPACITY ANGLE @ 45 DEGREES ......... 4" X 4" X 3/8"
CAPACITY ROUNDS ..................... 1-7/8"
CAPACITY SQUARES .................... 1-3/4"
CAPACITY FLATS ...................... 1" X 4" OR 1/4 "X 10"
CAPACITY TEES ....................... 4" X 4"X 3/8"
LENGTH OF BLADE ..................... 12"
DEPTH OF THROAT ..................... 20"
STROKE:.............................. 40"
NOTCHER ............................. YES
COPING .............................. YES
DUAL FOOT CONTROLS .................. YES
MAIN MOTOR .......................... 10 HORSEPOWER
