Brand
CARLTON
Type
Drills, Radial
Stock No.
21265
 |
419-269-2000 |
Stock #: 21265
SERIAL .............................. 4AMODEL ............................... 4AAREA OF BASE ........................ 84" X 51"SPINDLE SPEEDS ...................... (36) 12 TO 1200 RPMSPINDLE FEEDS ....................... (18) .004 TO .125 IPRSPINDLE STROKE ...................... 20"TAP LEADS ........................... 8, 11.5, 14, 18TAPER IN SPINDLE .................... 6 MTDISTANCE SPINDLE CENTER TO COLUMN ... 13-1/4" MIN, 6' MAXVERTICAL TRAVEL OF ARM .............. 56"POWER HEAD TRAVERSE ................. YESPOWER HEAD COLUMN CLAMPING .......... YESPOWER ELEVATION ..................... YESCOOLANT ............................. YESMOTOR ............................... 20 HORSEPOWER
