| Specifications | ||
|---|---|---|
| Tonnage | 60 tons | |
| Stroke | 3.5 inches | |
| Shut Height | 14 inches | |
| Bed W | 21 inches | |
| Bed L | 32 inches | |
| SPM | 90 | |
| Air Clutch (Yes/No) | no | |
| Type (BG, Double Action, FW) | flywheel | |
| Crank (Single/Double) | single | |
Brand
NIAGARA
Type
Presses, O.B.I.
Stock No.
10789
 |
419-269-2000 |
Stock #: 10789
SERIAL ...................... P52174MODEL ....................... E-60CAPACITY .................... 60 TONSSTROKE ...................... 3.5"SHUT HEIGHT ................. 14"SLIDE ADJUSTMENT ............ 3.5"STROKES PER MINUTE .......... 45 TO 90 SPM
SLIDE AREA .................. 21" LR X 16" FBBED AREA .................... 32" LR X 21" FBCONTROLS .................... INCH, SINGLE, CONTINUOUS
PALM BUTTON CONTROLS ........ YES
E-STOP ...................... YES
WINTRESS BRAKE MONITOR ...... YES
60" l-r x 64" f-b x 125" high
