SERIAL ................. 708
MODEL .................. G1200
YEAR ................... 1980
CAPACITY @ 12" ......... 120,000 LBS
CAPACITY @ 18 .......... 96,000 LBS
CAPACITY @ 24" ......... 80,000 LBS
TABLE SIZE ............. 120" X 120"
TABLE CENTER HEIGHT .... 98" FROM GROUND
TILT CAPACITY .......... 135 DEGREES
ROTATION SPEED ......... VARIABLE
PENDANT CONTROLS ....... YES
MAIN MOTOR ............. 15 HP
TILT MOTOR ............. 15 HP
| Specifications | ||
|---|---|---|
| Weight | 44000 pounds | |
Brand
ARONSON
Type
Welding Positioners
Stock No.
15007
 |
419-269-2000 |
Stock #: 15007
SERIAL ................. 708
MODEL .................. G1200
YEAR ................... 1980
CAPACITY @ 12" ......... 120,000 LBS
CAPACITY @ 18 .......... 96,000 LBS
CAPACITY @ 24" ......... 80,000 LBS
TABLE SIZE ............. 120" X 120"
TABLE CENTER HEIGHT .... 98" FROM GROUND
TILT CAPACITY .......... 135 DEGREES
ROTATION SPEED ......... VARIABLE
PENDANT CONTROLS ....... YES
MAIN MOTOR ............. 15 HP
TILT MOTOR ............. 15 HP
