Machine Information

42" X 288" TOS CELAKOVICE MODEL #SU100 ENGINE LATHE WITH 4.25" HOLE AND METRIC THREADING: STOCK 15151

Stock #: 15151

Equipped With

SERIAL ..................... 0443467
MODEL ...................... SU100
SWING OVER WAYS ............ 42"
SWING OVER CROSS SLIDE ..... 26"
DISTANCE BETWEEN CENTERS ... 288"
DIAMETER OF SPINDLE HOLE ... 4-1/8"
CHUCK ...................... 39.5" 4 JAW
SPINDLE SPEEDS ............. (36) 2.24 TO 458 RPM
FEEDS ENGLISH .............. YES
FEEDS METRIC ............... YES
THREAD ENGLISH ............. YES
THREDS METRIC .............. YES
4 WAY RAPID TRAVERSE ....... YES
4 WAY TOOL POST ............ YES
THREAD DIAL ................ YES
STEADY REST ................ 16" & 20.5"
TAILSTOCK .................. MOTORIZED
MOTOR ...................... 20 HORSEPOWER

Buy Machines

42" X 288" TOS CELAKOVICE MODEL #SU100 ENGINE LATHE WITH 4.25" HOLE AND METRIC THREADING: STOCK 15151

Stock # 15151

Share Machine
Print Details

Machine Specifications

SERIAL ..................... 0443467
MODEL ...................... SU100
SWING OVER WAYS ............ 42"
SWING OVER CROSS SLIDE ..... 26"
DISTANCE BETWEEN CENTERS ... 288"
DIAMETER OF SPINDLE HOLE ... 4-1/8"
CHUCK ...................... 39.5" 4 JAW
SPINDLE SPEEDS ............. (36) 2.24 TO 458 RPM
FEEDS ENGLISH .............. YES
FEEDS METRIC ............... YES
THREAD ENGLISH ............. YES
THREDS METRIC .............. YES
4 WAY RAPID TRAVERSE ....... YES
4 WAY TOOL POST ............ YES
THREAD DIAL ................ YES
STEADY REST ................ 16" & 20.5"
TAILSTOCK .................. MOTORIZED
MOTOR ...................... 20 HORSEPOWER
