Machine Information

4 HI (1) STAND FENN ROLLING MILL: STOCK 12252

Stock #: 12252

Equipped With

SERIAL ............................ 143
MODEL ............................. 4-053-C
SERIES ............................ 5
ROLL FACE ......................... 7.5" WIDE
WORK ROLL.......................... 1.625" DIA
BACKUP ROLL ....................... 5.250" DIA
BACKUP ROLL JOURNAL ............... 3.375" DIA
HOUSING POST DIMENSION ............ 4.875" x 5"
SEPERATION FORCE .................. 100,000lbs at 100fpm
MOTORIZED SCREW DOWNS ............. YES
CHAIN DRIVE FOR TAKE UP REEL ...... YES
COMBINATION PINION/REDUCER RATIO .. 15:1
MAIN MOTOR CAPACITY ............... 15 HP DC @ 600 RPM

NO MOTOR
NO DRIVE SHAFTS
