Stock #: 11851
SERIAL ....................... 1324MODEL ........................ 3XHDDRILLING CAPACITY ........... 2-1/8" MILD STEELCOLUMN DIAMETER .............. 7-7/8"CENTER OF SPINDLE TO COLUMN .. 16-1/2"MAX DIAMETER OF WORKPIECE .... 31-1/2"SPINDLE TRAVEL................ 10"SPINDLE TAPER ................ 5 MTSPINDLE SPEEDS ............... (12) 40 TO 1065 RPMSPINDLE FEEDS ................ (4) .013 TO .013 IPRARA OF TABLE ................. 22" X 22"AREA OF BASE ................. 26" X 25"TABLE ROTATES ................ 360 DEGREESTABLE TURNS .................. 360 DEGREESSPINDLE NOSE TO TABLE ........ 31" MAXIMUMSPINDLE NOSE TO BASE ......... 50-3/4" MAXIMUMCOOLANT ...................... YESMAIN MOTOR ................... 6-1/2 HORSEPOWER
Stock # 11851
SERIAL ....................... 1324
MODEL ........................ 3XHD
DRILLING CAPACITY ........... 2-1/8" MILD STEEL
COLUMN DIAMETER .............. 7-7/8"
CENTER OF SPINDLE TO COLUMN .. 16-1/2"
MAX DIAMETER OF WORKPIECE .... 31-1/2"
SPINDLE TRAVEL................ 10"
SPINDLE TAPER ................ 5 MT
SPINDLE SPEEDS ............... (12) 40 TO 1065 RPM
SPINDLE FEEDS ................ (4) .013 TO .013 IPR
ARA OF TABLE ................. 22" X 22"
AREA OF BASE ................. 26" X 25"
TABLE ROTATES ................ 360 DEGREES
TABLE TURNS .................. 360 DEGREES
SPINDLE NOSE TO TABLE ........ 31" MAXIMUM
SPINDLE NOSE TO BASE ......... 50-3/4" MAXIMUM
COOLANT ...................... YES
MAIN MOTOR ................... 6-1/2 HORSEPOWER
| Videos | ||
|---|---|---|
| Specifications | ||
|---|---|---|
| Dimensions | 42" X 24" X 103" | |
