SERIAL .......................... A814G759
| Specifications | ||
|---|---|---|
| Dimensions | 145 X 44 X 104" H | |
| Weight | 5800 pounds | |
| Max Table Load | 15000 pounds | |
Brand
W.F. WELLS
Type
Saws, Band, Horizontal
Stock No.
23678
 |
419-269-2000 |
Stock #: 23678
SERIAL .......................... A814G759
MODEL ........................... G-30-IICAPACITY (RECTANGULAR)........... 30" H X 36" WCAPACITY (ROUND) ................ 30"CAPACITY (AT 45 DEGREES) ........ 30" H X 24" WSAW BLADE ....................... 22'6" X 1.25" X .042"SAW SPEED ....................... 75 TO 500 FPMBLADE TENSIONING ................ HYDRAULICCLEARANCE UNDER BLADE ........... 32"
SAWING FORCE .................... 0 TO 300 LBS, VARIABLE
HEAD CYCLE TIME, LOWER .......... 32" IN 12 SECONDS
HEAD CYCLE TIME, RAISE .......... 32" IN 6 SECONDSHYDRAULIC DOWNFEED .............. VARIABLE
WEIGHT CAPACITY ................. 15,000 LBSHYDRAULIC VISE PRESSURE ......... 750 TO 4,500 LBS, VARIABLE
WORK TABLE HEIGHT ............... 27"OPERATOR CONSOLE ................ YESCOOLANT ......................... YESHYDRAULIC MOTOR ................. 2 HORSEPOWERBLADE MOTOR ..................... 5 HORSEPOWER
