Brand
LEWIS
Type
Wire Machinery (Other)
Stock No.
16182
 |
419-269-2000 |
Stock #: 16182
RMG DESCALER:SERIAL ........................ 97084263MODEL ........................ MD-14 L2RWire Capacity Size Range ...... 7/32" (5.5mm) - 9/16" (14mm)Left to Right Wire Flow ....... YESEntrance Guide Assembly ....... YESProduction Rate ............... Up to 500 FPMRMG DRAWER:Capstan ....................... 36"Maximum Speed ................. 200FPMMaximum Diameter .............. 5/8" (16mm)Motor.......................... 50 HPLEWIS STRAIGHTEN & CUT:MODEL ........................ 8CVWIRE DIAMETER ................ 5/32" TO 3/8"CUT OFF LENGTH ............... 3-1/2" TO 48"SPEED ........................ 100-200 FPMExit Rolls ................... YES
AC MOTOR AND CONTROLS ........ YES
GEARED TRANSMISSIO ........... YES
MECHANICAL TRIP .............. YES
