12.5" SPINDLE BORE WARNER & SWASEY MODEL #4A TURRET LATHE: STOCK #16045

Stock #: 16045

Equipped With

SERIAL ............................. 162523
MODEL .............................. M3580
LOT ................................ 8
SWING OVER WAYS .................... 29-1/2"
SWING OVER CARRIAGE ................ 22-7/16"
DISTANCE SPINDLE TO TURRET FACE .... 68-1/4"
SPINDLE SPEEDS ..................... (32) 15 TO 526 RPM
TURRET FEEDS ....................... (16) .005 TO .167 IPR
CROSS SLIDE FEEDS .................. (16) .002 TO .077 IPR
CROSS SLIDING TURRET FEEDS ......... (16) .003 TO .090 IPR
DIAMETER OF SPINDLE HOLE ........... **12-1/2"**
CHUCK .............................. 24" 3 JAW
RAPID TRAVERSE ..................... YES
CHIP PAN AND COOLANT ............... YES
CHIP CONVEYOR ...................... YES
MAIN MOTOR ......................... 50 HP

Buy Machines

12.5" SPINDLE BORE WARNER & SWASEY MODEL #4A TURRET LATHE: STOCK #16045

Stock # 16045

Share Machine
Print Details

Machine Specifications

SERIAL ............................. 162523
MODEL .............................. M3580
LOT ................................ 8
SWING OVER WAYS .................... 29-1/2"
SWING OVER CARRIAGE ................ 22-7/16"
DISTANCE SPINDLE TO TURRET FACE .... 68-1/4"
SPINDLE SPEEDS ..................... (32) 15 TO 526 RPM
TURRET FEEDS ....................... (16) .005 TO .167 IPR
CROSS SLIDE FEEDS .................. (16) .002 TO .077 IPR
CROSS SLIDING TURRET FEEDS ......... (16) .003 TO .090 IPR
DIAMETER OF SPINDLE HOLE ........... **12-1/2"**
CHUCK .............................. 24" 3 JAW
RAPID TRAVERSE ..................... YES
CHIP PAN AND COOLANT ............... YES
CHIP CONVEYOR ...................... YES
MAIN MOTOR ......................... 50 HP
