2500 DEGREE ABAR IPSEN MODEL VR-60X72 VERTICAL BOTTOM LOAD VACUUM FURNACE: STOCK #12696

Stock #: 12696

Equipped With

SERIAL ................... BM-362 1-183
TYPE ..................... BOTTOM LOAD VACUUM
MODEL .................... VR-60x72

CHAMBER SIZE ............. 60" DIAMETER x 72" H
TEMPERATURE RANGE ........ 1,000 TO 2,500 Degrees F
TEMPERATURE UNIFORMITY ... +/- 10 Degrees F
HEATER KVA RATING ........ 700
LOAD CAPACITY ............ 3,500 LBS
WATER TANK CAPACITY ...... 2,000 GALLONS
ARGON TANK CAPACITY ...... 1,500 GALLONS
IMECO COOLING TOWER ...... YES

Buy Machines

2500 DEGREE ABAR IPSEN MODEL VR-60X72 VERTICAL BOTTOM LOAD VACUUM FURNACE: STOCK #12696

Stock # 12696

Share Machine
Print Details

Machine Specifications

SERIAL ................... BM-362 1-183
TYPE ..................... BOTTOM LOAD VACUUM
MODEL .................... VR-60x72

CHAMBER SIZE ............. 60" DIAMETER x 72" H
TEMPERATURE RANGE ........ 1,000 TO 2,500 Degrees F
TEMPERATURE UNIFORMITY ... +/- 10 Degrees F
HEATER KVA RATING ........ 700
LOAD CAPACITY ............ 3,500 LBS
WATER TANK CAPACITY ...... 2,000 GALLONS
ARGON TANK CAPACITY ...... 1,500 GALLONS
IMECO COOLING TOWER ...... YES

Specifications
Chamber-W 60 inches
Chamber-H 72 inches
Max Temperature 2500 fahrenheit
