Machine Information

20,000 LB 10 TON 8" KURT MODEL PT800-A SINGLE STATION VISE WITH KURT SWIVEL HANDLE: STOCK 16051

Stock #: 16051

Equipped With

MODEL .............................. PT800-A
JAW WIDTH .......................... 8"
JAW DEPTH .......................... 2"
JAW OPENING ........................ 7.375"
OVERALL HEIGHT ..................... 5.5"
CLAMPING CAPACITY .................. 20,000 LB |10 TON
HEIGHT TOP OF BED TO TOP OF JAWS ... 2"
HEIGHT CLAMPING LEDGE .............. 23/32"
CENTER KEYWAY TO END OF FIXED JAW .. 8"
END BED TO END LEAD SCREW .......... 3-1/8"
MAXIMUM JAW OPENING ................ 7-3/8"
OPENING OF CLAMPING SLOT ........... 17/32"
OVERALL LENGTH ..................... 20"
WEIGHT ............................. 150 LBS
KURT SWIVEL HANDEL 80-24 ........... INCLUDED

Buy Machines

20,000 LB 10 TON 8" KURT MODEL PT800-A SINGLE STATION VISE WITH KURT SWIVEL HANDLE: STOCK 16051

Stock # 16051

Share Machine
Print Details

Machine Specifications

MODEL .............................. PT800-A
JAW WIDTH .......................... 8"
JAW DEPTH .......................... 2"
JAW OPENING ........................ 7.375"
OVERALL HEIGHT ..................... 5.5"
CLAMPING CAPACITY .................. 20,000 LB |10 TON
HEIGHT TOP OF BED TO TOP OF JAWS ... 2"
HEIGHT CLAMPING LEDGE .............. 23/32"
CENTER KEYWAY TO END OF FIXED JAW .. 8"
END BED TO END LEAD SCREW .......... 3-1/8"
MAXIMUM JAW OPENING ................ 7-3/8"
OPENING OF CLAMPING SLOT ........... 17/32"
OVERALL LENGTH ..................... 20"
WEIGHT ............................. 150 LBS
KURT SWIVEL HANDEL 80-24 ........... INCLUDED
