| Specifications | ||
|---|---|---|
| Dimensions | 65” x 123” x 97” | |
| Weight | 2700 pounds | |
Brand
HYD-MECH
Type
Saws, Band, Vertical
Stock No.
21928
 |
419-269-2000 |
Stock #: 21928
Capacity, Rectangular (h x w) 90° 22″ x 18″; 20-3/4″ x 18″ cant. head
CAPACITY, Round 90° 17-1/2″Capacity, Rectangular (h x w) 45° 15″ x 18″; 14″ x 18″ cant. head
CAPACITY, Round 45° 12-1/2″Capacity, Rectangular (h x w) 60° Right 10-1/4″ x 18″; 9-1/2″ x 18″ cant. head
CAPACITY, Round 60° Right 10-1/4″; 9-1/2″ cant. headBlade Size 1-1/4” x 16’ 3”Blade Drive 5 HP VFDMachine Voltage 480 v (all other voltages require optional transformer)Blade Speed 65 TO 385 SFMCoolant Tank Capacity 12 Gal.Table Height 36-1/2”• Adjustable 3° canted head• Double articulating, semi-automatic control• Two full stroking hydraulic vises• Manual precise head positioning from 60° left to 60° right• Digital angle display w/ protractor• Powered hydraulic guide arm• On-demand hydraulics save energy• 5 HP VFD. True direct blade drive – no belts/pulleys• Hydraulic positive down feed• Cast iron band wheels• Replaceable blade brush• Robust steel base• Easy access electrical panel and hydraulics• Blade breakage switch• Mechanical band tensioning with digital readout• Replaceable carbide guide inserts• 0.5 HP hydraulic pump provides system pressure• Safety door interlocks• Flood coolant with wash down hose• Laser light• Work light• Variable vise pressure
