SERIAL ................ 7952
MODEL ................. 71758
CAPAICTY .............. 175 TON
LENGTH OF BED & RAM ... 96"
BED WIDTH ............. 8-1/4"
RAM WIDTH ............. 5"
BETWEEN HOUSINGS ...... 78"
STROKE ................ 8"
OPEN HIEGHT ........... 14"
CLOSED HIEGHT ......... 6"
THROAT ................ 10"
APPROACH SPEED ........ 90 IPM
BEND SPEED ............ 24 IPM
RETURN SPEED .......... 180 IPM
CYCLE SPEED ........... 15 SPM
BED HIEIGHT ........... 34"
MOTOR ................. 20 HP
Specifications | ||
---|---|---|
Dimensions | OVERALL: WIDTH 130" - DEPTH 60" - HEIGHT 84" | |
Weight | 17000 pounds |
Brand
ACCURPRESS
Type
Brakes, Press
Stock No.
21170
![]() |
419-269-2000 |
Stock #: 21170
SERIAL ................ 7952
MODEL ................. 71758
CAPAICTY .............. 175 TON
LENGTH OF BED & RAM ... 96"
BED WIDTH ............. 8-1/4"
RAM WIDTH ............. 5"
BETWEEN HOUSINGS ...... 78"
STROKE ................ 8"
OPEN HIEGHT ........... 14"
CLOSED HIEGHT ......... 6"
THROAT ................ 10"
APPROACH SPEED ........ 90 IPM
BEND SPEED ............ 24 IPM
RETURN SPEED .......... 180 IPM
CYCLE SPEED ........... 15 SPM
BED HIEIGHT ........... 34"
MOTOR ................. 20 HP
