SERIAL ............................ 41940
MODEL ............................. 175X10 CB
CAPACITY .......................... 175 TONS
OVERALL LENGTH OF RAM & BED ....... 144"
DISTANCE BETWEEN HOUSINGS ......... 126"
STROKE ............................ 10"
OPEN HEIGHT ....................... 17"
THROAT ............................ 8"
RAM SPEED ......................... 132 IPM HIGH; 49 IPM MEDIUM; 14 IPM LOW
RAM RETURN SPEED .................. 95 IPM
CINCINNATI CONTROL ................ YES
MOTOR ............................. 35 HP
| Specifications | ||
|---|---|---|
| Tonnage | 175 tons | |
| Hyd/Mech | hydraulic | |
| OA Length | 12 feet | |
| OA (Overall) Length | 144 inches | |
| BH | 126.75 inches | |
| BH (Between Housings) | 126.75 inches | |
| Stroke | 10 inches | |
| # Axis | 2 | |
| Dimensions | 144" X 35" X 127" H | |
| Weight | 24000 pounds | |
Brand
CINCINNATI INC
Type
Brakes, Press
Stock No.
10214
 |
419-269-2000 |
Stock #: 10214
SERIAL ............................ 41940
MODEL ............................. 175X10 CB
CAPACITY .......................... 175 TONS
OVERALL LENGTH OF RAM & BED ....... 144"
DISTANCE BETWEEN HOUSINGS ......... 126"
STROKE ............................ 10"
OPEN HEIGHT ....................... 17"
THROAT ............................ 8"
RAM SPEED ......................... 132 IPM HIGH; 49 IPM MEDIUM; 14 IPM LOW
RAM RETURN SPEED .................. 95 IPM
CINCINNATI CONTROL ................ YES
MOTOR ............................. 35 HP
