SERIAL .......................... 517-95132
MODEL ........................... C-305A
YEAR ............................ 1995
Capacity (Rectangles) ........... 12" x 12"
Capacity (Rounds) ............... 12"
Single Automatic Index Length ... 24" Min
Butt End w/ Automatic Feed ...... 2.5"
Blade Size ...................... 144" x 1.25"
Wheel Diameter .................. 15"
Worktable Height ................ 30"
Material Pass Line Height ....... 30.5"
Band Speed ...................... 6 (0 FPM - 450 FPM)
CHIP AUGER ...................... YES
Motor ........................... 5 HP
| Specifications | ||
|---|---|---|
| Dimensions | 74" X 85" X 58" | |
Brand
DOALL
Type
Saws, Band, Horizontal
Stock No.
17575
 |
419-269-2000 |
Stock #: 17575
SERIAL .......................... 517-95132
MODEL ........................... C-305A
YEAR ............................ 1995
Capacity (Rectangles) ........... 12" x 12"
Capacity (Rounds) ............... 12"
Single Automatic Index Length ... 24" Min
Butt End w/ Automatic Feed ...... 2.5"
Blade Size ...................... 144" x 1.25"
Wheel Diameter .................. 15"
Worktable Height ................ 30"
Material Pass Line Height ....... 30.5"
Band Speed ...................... 6 (0 FPM - 450 FPM)
CHIP AUGER ...................... YES
Motor ........................... 5 HP
