STATIONS 12 + 1 AUXILIARY
DISTANCE BTWN STATIONS ..... 2-1/8"
MAX DIAMETER OF BLANK
1 ROW ...................... 1-1/2"
2 ROWS ..................... 1"
3 ROWS ..................... 9/16"
STROKE OF CAMS (STANDARD)
CAM #1 ..................... 1-3/8"
CAM #2 & #3 ................ 1-5/8"
CAM #4 THRU #12 ............ 1-7/8"
MAX DEPTH OF DRAWN SHELL ... 11/16" (MAY BE INCREASED BY APPLICATION)
SPEED ...................... UP TO 275 SPM
ROLLER CAM FOLLOWERS
ROUND PLUNGERS
AC MOTOR DRIVE
VARIABLE FREQUENCY DRIVE CONTROLS,
CLARKTRON RIMFIRE TRANSFER PRESS MONITORING SYSTEM,
OPERATOR SAFETY ENCLOSURES
WEIGHT ..................... 4,100#
Brand
WATERBURY FARREL
Type
Presses, Transfer
Stock No.
15378
 |
419-269-2000 |
Stock #: 15378
STATIONS 12 + 1 AUXILIARY
DISTANCE BTWN STATIONS ..... 2-1/8"
MAX DIAMETER OF BLANK
1 ROW ...................... 1-1/2"
2 ROWS ..................... 1"
3 ROWS ..................... 9/16"
STROKE OF CAMS (STANDARD)
CAM #1 ..................... 1-3/8"
CAM #2 & #3 ................ 1-5/8"
CAM #4 THRU #12 ............ 1-7/8"
MAX DEPTH OF DRAWN SHELL ... 11/16" (MAY BE INCREASED BY APPLICATION)
SPEED ...................... UP TO 275 SPM
ROLLER CAM FOLLOWERS
ROUND PLUNGERS
AC MOTOR DRIVE
VARIABLE FREQUENCY DRIVE CONTROLS,
CLARKTRON RIMFIRE TRANSFER PRESS MONITORING SYSTEM,
OPERATOR SAFETY ENCLOSURES
WEIGHT ..................... 4,100#
