STATIONS 12 + 1 AUXILIARY
DISTANCE BTWN STATIONS - 2-1/8"
MAX DIAMETER OF BLANK
1 ROW - 1-1/2"
2 ROWS- 1"
3 ROWS - 9/16"
STROKE OF CAMS (STANDARD)
CAM #1- 1-3/8"
CAM #2 & #3 1-5/8"
CAM #4 THRU #12 - 1-7/8"
MAX DEPTH OF DRAWN SHELL - 11/16" (MAY BE INCREASED BY APPLICATION)
SPEED - UP TO 275 SPM
ROLLER CAM FOLLOWERS
ROUND PLUNGERS
AC MOTOR DRIVE
VARIABLE FREQUENCY DRIVE CONTROLS,
CLARKTRON RIMFIRE TRANSFER PRESS MONITORING SYSTEM,
OPERATOR SAFETY ENCLOSURES
WEIGHT - 4,100#
Brand
WATERBURY FARREL
Type
Presses, Transfer
Stock No.
15376
 |
419-269-2000 |
Stock #: 15376
STATIONS 12 + 1 AUXILIARY
DISTANCE BTWN STATIONS - 2-1/8"
MAX DIAMETER OF BLANK
1 ROW - 1-1/2"
2 ROWS- 1"
3 ROWS - 9/16"
STROKE OF CAMS (STANDARD)
CAM #1- 1-3/8"
CAM #2 & #3 1-5/8"
CAM #4 THRU #12 - 1-7/8"
MAX DEPTH OF DRAWN SHELL - 11/16" (MAY BE INCREASED BY APPLICATION)
SPEED - UP TO 275 SPM
ROLLER CAM FOLLOWERS
ROUND PLUNGERS
AC MOTOR DRIVE
VARIABLE FREQUENCY DRIVE CONTROLS,
CLARKTRON RIMFIRE TRANSFER PRESS MONITORING SYSTEM,
OPERATOR SAFETY ENCLOSURES
WEIGHT - 4,100#
