Stock #: 17903
SERIAL ..................... 21857
MODEL ...................... HYD 110
YEAR NEW ................... 2007CAPACITY ................... 110 TONPUNCHING CAPACITY .......... 1-1/2" X 3/4" THICKDEPTH OF THROAT ............ 12"STROKE ..................... 3"SHEAR FLATS ................ 24" x 5/8"; 16" x 3/4"LENGTH OF BLADES ........... 24"ANGLE SHEAR CAPACITY ...... 6-1/2" X 6-1/2" X 1/2"ANGLE SHEAR @ 45 DEGREES ... 3" X 3" X 5/16"BARS ....................... 2", SQUARE BARS 2"NOTCHER .................... SHEET METAL 1/2", ANGLE IRON 4"NOTCHER DEPTH & WIDTH ...... 3-1/2" X 2"STROKES PER MINUTE ........ 20 @ 3/4"DUAL RAMS .................. YES
FOOT PEDALS ................ YES
MOTOR ...................... 7-1/2 HP
Stock # 17903
SERIAL ..................... 21857
MODEL ...................... HYD 110
YEAR NEW ................... 2007CAPACITY ................... 110 TON
PUNCHING CAPACITY .......... 1-1/2" X 3/4" THICK
DEPTH OF THROAT ............ 12"
STROKE ..................... 3"
SHEAR FLATS ................ 24" x 5/8"; 16" x 3/4"
LENGTH OF BLADES ........... 24"
ANGLE SHEAR CAPACITY ...... 6-1/2" X 6-1/2" X 1/2"
ANGLE SHEAR @ 45 DEGREES ... 3" X 3" X 5/16"
BARS ....................... 2", SQUARE BARS 2"
NOTCHER .................... SHEET METAL 1/2", ANGLE IRON 4"
NOTCHER DEPTH & WIDTH ...... 3-1/2" X 2"
STROKES PER MINUTE ........ 20 @ 3/4"
DUAL RAMS .................. YES
FOOT PEDALS ................ YES
MOTOR ...................... 7-1/2 HP
