SERIAL ........................ 28204
NEW ........................... 1994
NUMBER OF ROLLFORM HEADS ...... 10
ROLLFOMER BASE ................ 12 STAND MAX
ARBOR DIAMETER ................ 3"
ROLL SPACE .................... 12"
HORIZONTAL CENTERS ............ 18"
BASE TO BOTTOM SPINDLE ........ 7.5"
VERTICAL ADJUSTMENT ........... 5" TO 9"
GEARBOXES ..................... 20:1
TOP & BOTTOM DRIVE ............ GEARED
MOTOR ......................... 25 HP DC
COOLANT MOTOR ................. 1/2 HP
| Specifications | ||
|---|---|---|
| Dimensions | 23' x 80" x 72" HIGH | |
| Weight | 14500 pounds | |
Brand
BRADBURY
Type
Roll Formers
Stock No.
13424
 |
419-269-2000 |
Stock #: 13424
SERIAL ........................ 28204
NEW ........................... 1994
NUMBER OF ROLLFORM HEADS ...... 10
ROLLFOMER BASE ................ 12 STAND MAX
ARBOR DIAMETER ................ 3"
ROLL SPACE .................... 12"
HORIZONTAL CENTERS ............ 18"
BASE TO BOTTOM SPINDLE ........ 7.5"
VERTICAL ADJUSTMENT ........... 5" TO 9"
GEARBOXES ..................... 20:1
TOP & BOTTOM DRIVE ............ GEARED
MOTOR ......................... 25 HP DC
COOLANT MOTOR ................. 1/2 HP
